PD INJECTOR STABILIZER 2.5 TDI engine VW T5

PD INJECTOR STABILIZER 2.5 TDI engine VW T5

Suitable for VW TDI 5 cylinder engines with pump-nozzle-unit technology (all engine codes)

€349,00 EUR
€380,00 EUR €349,00 EUR
Sale Sold out
Taxes included. Shipping calculated at checkout.

● In stock

The simple and durable solution!

The PD INJECTOR STABILIZER: CNC-milled from tool steel for maximum stability, heat resistance and wear resistance - perfect for the high loads in the engine compartment. Aluminum, on the other hand, can deform, wear out more quickly and does not offer the same durability.


Effective problem solving instead of expensive replacement: Vehicles with the known damage pattern can be repaired cost-effectively with our INJECTOR STABILIZER without having to invest directly in a costly replacement of the cylinder heads.


Developed in cooperation with master car mechanics and produced in Germany in a master tool and mold making company.


Already installed 1000 times


3-Months Return Policy! Because our INJECTOR STABILIZER is so stable, it can be installed and removed without any signs of wear. See for yourself and test the PDE bridge.


Tip: With our new RAPID INJECTOR STABILIZER, all injection nozzles are individually fixed and stabilized. This allows you to remove and reseal just the problem injector without having to remove the other injectors. This efficient approach saves time, material and costs, as unnecessary disassembly is avoided and the repair process is significantly faster.

3-months Return Policy

Risk-free trial:

Try out the INJECTOR STABILIZER without any obligation. If the product does not meet your expectations, you can return it without any problems - you only pay the shipping costs.

For excessively damaged motors

Even engines that are already severely damaged can still be saved. Install our reinforced sealing rings These are slightly thicker and provide a reinforced seal.

Installation

  1. Disconnect the electrical plugs, then remove the injector screws and tension shoes.

  2. Remove injectors.

  3. Check the sealing surfaces in the cylinder for burrs and remove them if necessary / re-seal pump-nozzle-unit / new injector screws usw.

  4. Insert the first injector into the 1st cylinder with the original clamp shoe (do not tighten yet).

  5. Put the INJECTOR STABILIZER together with the other 4 pump-nozzle-elements and then screw all 5 injection nozzles evenly into the inserts.

  6. The alignment is done automatically and the engine is ready for use again, without any oil build-up or starting problems.

Instructions for use

The INJECTOR STABILIZER is also available as a set with all the attachments you need:

INJECTOR REPAIR KIT 2.5 TDI

Alternatively, you can also use our RAPID INJECTOR STABILIZER for your 5-cylinder engine and benefit from its advantages. This offers a completely new repair option. Feel free to compare:

INJECTOR RAPID STABILIZER

INJECTOR RAPID REPAIR KIT - 5 CYLINDER ENGINE

After pulling the injectors, they must be reset, preferably with our Reinforced sealing rings. New Injector screws are also required.

Disclaimer of liability:
At no time can we guarantee an improvement. Rather, we assure you that our product will bring about an improvement in most cases. It is at your discretion to use our product. We completely exclude consequential damage of any kind.

Scope of delivery

1x INJECTOR STABILIZER 2.5 TDI

Shipping information

Delivery time: available immediately after receipt of payment

We calculate the shipping costs for this product at 10,10€ per order in Germany (different delivery prices abroad).

View full details

Die schnelle Alternative zur PDE Brücke:

Der PDE Schnellwechsel Reparaturhalter fixiert jede PDE-Einspritzdüse einzeln, und sorgt dafür, dass diese wieder in Ursprungsposition kommen & nicht mehr vibrieren können. So bleiben die Dichtringe in ihrer Sollposition & dichten wieder richtig ab. Da der PDE Schnellwechsel Reparaturhalter einfach anstatt des original Klemmschuhs eingebaut werden kann, ist kein Ausbau der PDEs notwenig. So sparst du dir ne menge Zeit & hast keine kosten für neue Anbauteile die man beim Ausbau der PDEs wechseln sollte.

Wenn dein PDE-Problem weiterhin besteht, liegt das daran das sich die PDEs durch Vibrationen stärker in den Zylinderkopf gearbeitet haben. Jetzt kannst du immer noch Verstärkte Dichtungen einbauen und sie mit dem Schnellwechsel Reparaturhalter vibrations frei in fixieren.

The INJECTOR REPAIR KITs

The ALL-INCLUSIVE package

View all
PDE Brücke

The INJECTOR STABILIZER

The manufacture of our INJECTOR STABILIZER & RAPID INJECTOR STABILIZER to eliminate starting difficulties is legally protected (certificate of registration of utility model no. 20 2020 004 529). Buy only directly from the manufacturer.
